TOWMAX VANGUARD | Towmax Tires

PREMIUM ST RADIAL TRAILER

The Towmax Vanguard is designed to be the industry standard for quality and performance. The next generation in the Towmax family, it provides significant enhancements in performance and appearance, while maintaining industry-leading durability.

Features

Next-generation Towmax technology
Optimized tread depth for reduced heat build-up
Decoupling grooves to minimize irregular wear
Wide shoulders for improved stability
Scuff Protector to reduce sidewall damage
Nylon overlays on all sizes for superior strength and durability
Nationwide Limited Warranty
2-Year Nationwide Roadside Assistance Program
1-Year Road Hazard Protection Plan

Media Center

Applications

RV Trailers
5th Wheel Trailers

Utility Trailers
Boat Trailers

Sizes and Specifications

ARTICLE #	SIZE	LR/PR	SERVICEDESCRIPTION	TREAD DEPTH(32NDS)	TYPE	R.W.(INCH)	O.D.(INCH)	S.W.(INCH)	WEIGHT(LBS)	SINGLEMAX LOAD(LBS)	INFL. P.(PSI)

13” (2 Sizes)

TBC-MAXV14	ST175/80R13	D/8	97/93	8	TL	5.00	24.0	7.0	18	1610	65
TBC-MAXV16	ST185/80R13	D/8	99/95	8	TL	5.00	24.7	7.2	20	1710	65

14” (3 Sizes)

TBC-MAXV36*	ST205/75R14	C/6	100/96	8	TL	5.50	26.1	8.0	21	1760	50
TBC-MAXV37	ST205/75R14	D/8	105/101	8	TL	5.50	26.1	8.0	23	2040	65
TBC-MAXV39	ST215/75R14	D/8	108/103	8	TL	6.00	26.7	8.5	24	2200	65

15” (4 Sizes)

TBC-MAXV48*	ST205/75R15	C/6	101/97	8	TL	5.50	27.1	8.0	23	1820	50
TBC-MAXV49	ST205/75R15	D/8	107/102	8	TL	5.50	27.1	8.0	25	2150	65
TBC-MAXV51*	ST225/75R15	D/8	113/108	8	TL	6.00	28.3	9.2	28	2540	65
TBC-MAXV53	ST225/75R15	E/10	117/112	8	TL	6.00	28.3	9.2	29	2860	80

16” (4 Sizes)

TBC-MAXV17	ST235/85R16	E/10	125/121	8	TL	6.50	31.7	9.3	37	3640	80
TBC-MAXV18	ST235/85R16	F/12	128/124	8	TL	6.50	31.7	9.3	39	3960	95
TBC-MAXV24	ST235/80R16	E/10	124/120	8	TL	6.50	30.8	9.3	34	3520	80
TBC-MAXV25	ST235/80R16	F/12	127/122	8	TL	6.50	30.8	9.3	35	3860	100
